Molecular Sieve Desiccant Of Air Condition System In Truck Or Car
Products Introduction
Xi'an Lvneng was specially developed for optimum performance in the dehydration of air for use in mobile compressed air brake systems, such as those used on trucks, coaches and railway rolling stock. In this PSA application, the quality requirements, especially regarding the physical stability of the product, is extremely high. Therefore these types of products are guaranteed to last for thousands of cycles under the extreme conditions experienced over the lifetime of the product.
Technical Parameter
Air Brake System Drying Molecular Sieve Typical Physical Properties | ||||
Items | Unit | 10*14 Mesh | 8*12 Mesh | |
Bead Size | mm | 1.5-2.0 | 1.6-2.5 | |
Bulk Density | g/ml ≥ | 0.70-0.80 | 0.70-0.80 | |
Equilibrium Water Capacity @ 25℃ | wt% ≥ | 19.0-21.0 | 19.0-21.0 | |
Heat of Adsorption | BTU/lb of H2O | 1800 | 1800 | |
Crush Strength | Point Contact | N ≥ | 35-70 | 50-100 |
Variation Coefficient | - | 0.3 | 0.3 | |
Attrition Rate | Dry | wt% ≤ | 0.1 | 0.1 |
Wet | wt% ≤ | 1.5 | 1.5 | |
Size Qualification | % ≥ | 97 | 97 | |
Package Moisture | wt% ≤ | 1.5 | 1.5 | |
The interval value of the indexes above are on the basis of the different grade of Air Brake System Desiccant |
Packaging
1, 25KG/carton; 2, 35KG/carton drum; 3, 150KG/Sealed iron drum
Delivery Time
About 3-15 days after the payment.
