13x Molecular Sieve Desiccant For General Gas (Such As Compressed Air, Permanent Gas) Deeply Drying
Introduction
Has a pore size of roughly 10A. This is considerably larger than any of the A-type openings. This desiccant is used primarily for refinements of liquid and gases because it offers synchronized absorption for bi-molecule and tri-molecule. It can co-adsorb CO2 and H2O, H2O and H2S. 13X Mole sieve also has applications as a desiccant for medical and compressor uses and as a c catalyze carrier. The sequence rate of adsorption is SF6, CHCL3, CHBr3, CHI3, N-C3F8, CCL4, N-C4F10, N-C7H16, CBr4, C6H6, B5H10, (CH3)3N, C(CH4)4, (C2H5)3N, C(CH3)C3CL, C(CH3)3Br, and C(CH3)3CH.
It has become one of the most reliable desiccants for a variety of applications including:
Air refining by removing carbon dioxide and water.
Oxygen PSA (Pressure Swing Adsorption) process.
Removal of grease and solvents.
Removal of mercaptans and hydrogen sulfide from natural gas using patented Zeochem technology.
Removal of mercaptans and hydrogen sulfide from hydrocarbon liquid.
Technical Parameter
| Molecular Sieve 13X Typical Physical Properties | ||||
| Items | Unit | 8*12 Mesh | 4*6 Mesh | |
| Bead Size | mm | 1.6-2.5 | 3.0-5.0 | |
| Bulk Density | g/ml ≥ | 0.68-0.85 | 0.65-0.80 | |
| Equilibrium Water Capacity @ 25℃ | wt% ≥ | 24.0-27.0 | 24.0-27.0 | |
| Equilibrium Carbon Dioxide Capacity | wt% ≥ | 18 | 18 | |
| Heat of Adsorption | BTU/lb of H2O | 1800 | 1800 | |
| Crush Strength | Point Contact | N ≥ | 30-80 | 80-130 |
| Variation Coefficient | - | 0.3 | 0.3 | |
| Attrition Rate | wt% ≤ | 0.1 | 0.1 | |
| Size Qualification | % ≥ | 97 | 97 | |
| Package Moisture | wt% ≤ | 1.5 | 1.5 | |
| The interval value of the indexes above are on the basis of the different grade of Molecular Sieve 13X | ||||
Attention:
